廚房排煙管道是家居裝修中需要注意的關鍵因素，不合理的廚房排煙管道會影響廚房的正常使用。那么廚房排煙管道考慮方面以及結構要求的相關內容是什么呢？
Kitchen smoke exhaust pipe is the key factor that needs attention in home decoration. Unreasonable kitchen smoke exhaust pipe will affect the normal use of the kitchen. So what are the considerations and structural requirements of kitchen smoke exhaust pipe?
廚房排煙管道考慮方面
Kitchen smoke exhaust pipe considerations
管道位置
Pipe location
以公用壁爐通風口為例，在廚房裝修前，應仔細考察公用壁爐的位置，確定合理的壁爐安裝位置。煙囪安裝的高度和方向、底座的方向、煙囪的行進方式、彎曲方式、吊頂、橫梁和墻壁的通道都經過精心規劃。
Taking the vent of public fireplace as an example, before kitchen decoration, the location of public fireplace should be carefully inspected to determine the reasonable installation location of fireplace. The installation height and direction of the chimney, the direction of the base, the traveling mode and bending mode of the chimney, and the channels of the ceiling, beam and wall have been carefully planned.
管道長度
Pipe length
開口越靠近公共煙道，管道對排氣的影響越小，排氣越亮。管道長度可控制在2米以內在1.5米以內。煙道的開口位置也提前規劃好了。煙道不長而高，煙道密封在天花板上，使煙道很容易排氣，既兼顧了美觀，又減少了掛箱的空間。
The closer the opening is to the public flue, the smaller the impact of the pipeline on the exhaust and the brighter the exhaust. The pipe length can be controlled within 2 meters and 1.5 meters. The opening position of the flue is also planned in advance. The flue is not long and high, and the flue is sealed on the ceiling, so that the flue is easy to exhaust, which not only takes into account the beauty, but also reduces the space for hanging the box.
避免使用家用電器
Avoid using household appliances
廚房排風管應遠離電纜，應避開各種家具、電器設備、天花板和墻壁障礙物。所以，如果不是關于之前房間的裝修，先確定煙管的方向，然后穩定煙機周圍的吊箱。
The kitchen exhaust duct should be far away from cables and should avoid all kinds of furniture, electrical equipment, ceiling and wall obstacles. Therefore, if it is not about the decoration of the previous room, first determine the direction of the smoke pipe, and then stabilize the hanging box around the smoke machine.
管材
Pipe
一些管道材料，如PVC管和金屬管，一般有直線曲線。注意盡量減少彎曲次數，并使用柔性鋁箔或塑料軟管。曲率線相對敏感。與鋼管相比，可以走短一點的路，否則日常油煙會逐漸凝結在油水混合物中，積聚在井內，影響排煙效果。
Some pipe materials, such as PVC pipe and metal pipe, generally have straight lines and curves. Pay attention to minimize the number of bends and use flexible aluminum foil or plastic hose. The curvature line is relatively sensitive. Compared with the steel pipe, it can take a shorter Road, otherwise the daily oil fume will gradually condense in the oil-water mixture and accumulate in the well, affecting the smoke exhaust effect.
廚房排煙管道的結構要求
Structural requirements of kitchen smoke exhaust pipe
排煙的目的是通過排煙機將室內的煙塵排放到室外，通風可以迫使室內外空氣在機內循環，它的通風方向和位置不同。其次，循環空氣的質量不同，不能使用同一管道。否則，如果在通風時不小心讓煙塵進入室內，會適得其反。
The purpose of smoke exhaust is to discharge the indoor smoke and dust outdoors through the smoke exhaust fan. Ventilation can force the indoor and outdoor air to circulate in the machine. Its ventilation direction and position are different. Secondly, the same air circulation quality cannot be used. Otherwise, if the smoke and dust enter the room carelessly during ventilation, it will be counterproductive.
排煙管道外表面與木材等可燃物的距離不應小于15cm，或排煙管道外表面應覆蓋不小于10cm厚的保溫材料進行保溫。
The distance between the outer surface of the smoke exhaust pipe and wood and other combustibles shall not be less than 15cm, or the outer surface of the smoke exhaust pipe shall be covered with thermal insulation materials not less than 10cm thick for thermal insulation.
排煙管道穿過擋煙罩時，風管與擋煙罩之間的間隙應用水泥砂漿等不燃材料填緊。
When the smoke exhaust pipe passes through the smoke shield, the gap between the air duct and the smoke shield shall be filled with incombustible materials such as cement mortar.
排煙管道與排氣扇的連接應采用法蘭或不燃柔性連接。
The connection between smoke exhaust pipe and exhaust fan shall adopt flange or non combustible flexible connection.
需要保溫的金屬煙道宜選用礦棉、玻璃棉、巖棉、硅酸鋁等不燃保溫材料。
Nonflammable thermal insulation materials such as mineral wool, glass wool, rock wool and aluminum silicate should be selected for metal flue requiring thermal insulation.
濟南廚房排煙人員提醒您，排煙管的材料應選用耐火性好的材料。排煙位置應根據建筑物的情況確定，應避開有燃燒危險的部位。
Jinan kitchen smoke exhaust personnel remind you that the materials of smoke exhaust pipes should be materials with good fire resistance. The smoke exhaust position shall be determined according to the situation of the building, and the parts with combustion risk shall be avoided.
