飯店油煙機排煙罩其特征在于由罩體和罩蓋上下兩部分構成，罩體由三個平面組成，內腔采用大空間設計使得油煙雜質的吸收變得更充分，下面濟南排煙罩廠家來講講飯店油煙機排煙罩的制作安裝與養護事項吧。

The smoke exhaust hood of hotel hood is characterized by the hood body and the upper and lower parts of the hood. The hood body is composed of three planes. The internal cavity is designed with a large space to make the absorption of oil smoke impurities more sufficient. Let's talk about the production, installation and maintenance of the smoke exhaust hood of hotel hood from Jinan smoke exhaust hood manufacturer.

飯店油煙機排煙罩制作要求

Manufacturing requirements for exhaust hood of hotel range hood

1.油網煙罩后封板、前封板、前頁、上滑槽與下滑槽所有外露邊均壓扣邊;

1. All exposed edges of the rear sealing plate, front sealing plate, front page, upper chute and lower chute of the oil screen smoke hood shall be crimped;

2.油網煙罩后封板與前封板連接為分段短焊，其中前封板HL面外露；

2. The connection between the rear sealing plate of the oil screen hood and the front sealing plate is short welding in sections, and the HL surface of the front sealing plate is exposed;

3.油網煙罩前頁與油網煙罩前封板連接為分段短焊，焊接面在前封板外露面前頁HL面向下，二端煙罩連接口分別向上90度；

3. The connection between the front page of the oil screen hood and the front sealing plate of the oil screen hood is segmented short welding. The welding surface is facing downward on the front page HL of the exposed surface of the front sealing plate, and the connection port of the two ends of the hood is 90 degrees upward respectively;

4.油網煙罩二末端的油煙網罩側封板與后封板、前封板前頁為分段短焊，其中同前頁的前端（注：尺寸120mm）、后封板去油槽位置為滿焊并打磨；

4. The side sealing plate of the oil screen hood at the two ends of the oil screen hood, the rear sealing plate and the front page of the front sealing plate are short welded in sections, wherein the front end (Note: size: 120mm) and the oil removal groove of the rear sealing plate are full welded and polished;

5.煙罩照明燈須有防水功能，導電線要有轉悠穿線護管。

5. The smoke hood lighting lamp shall have waterproof function, and the conductive wire shall be provided with a rotating threading protective tube.

飯店油煙機排煙罩安裝方法

Installation method of exhaust hood of hotel range hood

飯店油煙機排煙罩安裝方法

Installation method of exhaust hood of hotel range hood

1.油煙網罩現場安裝時，在現場拼接的油網煙罩后封板去油槽位置為滿焊，其余位置為分段短焊；

1. When the oil fume hood is installed on site, the position of the oil removal groove of the rear sealing plate of the oil fume hood spliced on site is full welding, and the other positions are short welding by sections;

2.油煙網罩與墻面固定用M8鋼膨脹螺絲加不銹鋼大墊片，膨脹螺絲外露螺紋需磨去；

2. M8 steel expansion screws and large stainless steel gaskets shall be used to fix the hood and the wall. The exposed threads of the expansion screws shall be removed;

3.油網煙罩前頁同樓板連接件為螺桿全絲或鋼絲繩加吊環螺釘、索具螺旋扣；

3. The connecting piece on the front page of the oil screen smoke hood and the floor shall be screw full wire or steel wire rope with eyebolt and sling screw buckle;

4.吊裝高度：油網煙罩前頁下口離地2000mm，油網煙罩后封板去油槽底部離地1900mm；油網煙罩吊裝水平精度一般全長在正負10mm.

4. Lifting height: the lower opening of the front page of the oil screen hood is 2000mm above the ground, and the bottom of the oil tank of the rear sealing plate of the oil screen hood is 1900mm above the ground; The lifting horizontal accuracy of oil screen hood is generally within plus or minus 10mm

飯店油煙機排煙罩養護方法

Maintenance method of exhaust hood of hotel range hood

1.不銹鋼櫥柜在平時避免熱鍋或者熱水壺直接和櫥柜進行直接接觸，這些物品好放在鍋架上面。

1. The stainless steel cabinet should avoid the direct contact between the hot pot or hot water pot and the cabinet. These items should be placed on the pot rack.

2.平時注意尖銳的物品不能觸及臺面，避免廚房排煙罩造成櫥柜上面有劃痕或者使櫥柜表面出現凹痕。

2. At ordinary times, sharp objects shall not touch the table top to avoid scratches on the cabinet or dents on the cabinet surface caused by the kitchen smoke exhaust hood.

3.櫥柜的門板根據不同的材質進行不同的清潔方法。

3. The door panel of the cabinet shall be cleaned according to different materials.

4.避免使用化學物質接觸到櫥柜，造成對櫥柜的損壞。

4. Avoid using chemicals to contact the cabinet and cause damage to the cabinet.

飯店油煙機排煙罩的制作安裝與養護的相關事項就講解到這里了，如果您對此有采購的需要或者說有什么疑問，就來我們網站http://www.zypolishing.com聯系有關人員咨詢吧。

That's all about the production, installation and maintenance of the exhaust hood of the hotel range hood. If you need to purchase or have any questions about this, please come to our website http://www.zypolishing.com Contact the relevant personnel for consultation.
