1、自垂百葉(自垂百葉式風口具有正壓的空調房間自動排氣。山東通風管道加工通常情況下靠風口的百葉自重而自然下垂，隔絕室內外的空氣交換，當室內氣壓大于室外氣壓時，氣流將百葉吹開而向外排氣，反之室內氣壓小于室外氣壓時，氣流不能反向流入室內，該風口有單向止回作用。)

　　1, since the vertical shutter (self vertical air inlet, with positive pressure air conditioning room, automatic exhaust. Shandong usually rely on ventilation pipe plus louver tuyere and the weight of natural sag, isolated from indoor and outdoor air exchange, when the indoor pressure is greater than the outdoor air pressure, air will blow and exhaust louver outward, and indoor air pressure less than the outdoor air pressure, air flow can not reverse the air into the room, a check).

　　2、活動百葉(雙層百頁風口一般作為送風口，也可直接與風機盤管配套使用，廣泛用于集中空調系統的末端，還可以與對開多葉調節閥,用以調整風量。單層百葉風口可調上下風向，回風口可與風口過濾網合用，節片角度可以調節,葉片間有ABS塑料固定支架。固定式過濾網在清洗時可由滑道上取出過濾網，清洗后再從滑道推入后繼續使用。)

　　2, blind (double hundred pages in general as air outlet, can also be used directly, and fan coil matching is widely used in the end, the central air conditioning system can also with multi leaf off valve to adjust the air volume. Single louver adjustable upper and lower wind, the air inlet can be combined with air filter, proglottis angle can be adjusted, the blade between ABS plastic bracket. When the fixed filter screen is cleaned, the filter screen can be taken out from the slideway, and then used again after being pushed from the slideway

　　3、防雨百葉風口(單層防雨百葉風口,雙層防雨百葉風口，自垂百葉防雨風口)

　　3 、 rainproof louver (single layer rainproof louver, double layer rainproof louver, self raised louver rainproof air outlet)

　　4、風口調節閥(散流器調節閥，百葉風口調節閥)

　　4 、 air outlet control valve (diffuser regulator valve, louver valve)

　　5、散流器(方、矩形散流器,LFK-7活葉條縫型散流器，條形直片散流器，扁葉散流器)

　　5, the diffuser (square diffuser, LFK-7 hinge slot diffuser, bar straight vane diffuser, flat leaf Sanliu device)

　　6、固定百葉(側壁格柵式風口，可開式側壁格柵風口)

　　6, fixed shutter (side wall grille type, can open side wall grille tuyere)

　　7、風口過濾器(鋁合金過濾器，網式鋼制過濾器)

　　7 、 air outlet filter (aluminium alloy filter, mesh type steel filter)

　　8、平面加固是將加固支撐按需加強風管的邊長用砂輪切割機下料，切斷DN15鍍鋅管。在鍍鋅管兩端，各放入60mm長圓木條。用夾鉗將圓木條固定在鍍鋅管兩端。

　　8, plane reinforcement is to strengthen the support as needed, strengthen the side length of the wind pipe, use grinding wheel cutting machine blanking, cut off the DN15 galvanized pipe. At both ends of galvanized pipe, each into oblong wood 60mm. Clamp the round bar at the ends of the galvanized pipe with tongs.

　　按設計要求用鋼尺在風管面確定加強點。邊長≧2000mm需增加外加固，外加固采用∠30*3以上角鋼制作成抱箍狀，箍緊風管。

　　According to the design requirements for steel pipe surface determined to strengthen the point in the wind. The length of more than 2000mm to increase the external reinforcement, plus solid angle 30*3 angle made by the hoop, hoop wind pipe.
