1、運水集氣(煙)罩：運水集氣(煙)罩的設計原理是形成水幕循環，與油煙碰撞后達到凈化油煙的目的。影響運水集氣(煙)罩使用效果的關鍵是要形成連續的水幕而只是形成了斷續流動的水滴或小水柱，因此使用效果非常差。

　　1, the water transport gas (smoke) Hood: water transport gas (smoke) hood design principle is to form a water curtain cycle, and after soot collision, to achieve the purpose of soot purification. The key to influence the effectiveness of the water transport (gas) hood is to form a continuous water screen, but only to form intermittent water droplets or small water column, so the use effect is very poor.

　　2、使用運水集氣(煙)罩的優點是能夠在集氣(煙)罩處除掉部分油煙，減輕油煙凈化設備的處理負荷，提高系統的凈化效果。但如果運水集氣(煙)罩的過煙縫隙較窄，容易引起排煙系統不通暢。

　　2, the advantages of using the water collection gas (smoke) cover is to remove part of the soot in the gas collection hood, reduce the handling load of soot purification equipment, and improve the purification effect of the system. But if the exhaust gas collector (smoke) cover of the smoke gap is narrow, easy to cause smoke exhaust system is not smooth.

　　3、濟南排煙罩的設計對于排煙系統具有重要的影響。集氣罩設計不合理就很容易造成整個排煙系統不暢。引起排煙系統不通暢的因素有：

　　The design of /3 and gas collecting hood has important influence on smoke exhaust system. The design of the gas collecting hood is unreasonable, and it is easy to cause the whole smoke exhaust system to be impeded. There are some factors causing the smoke exhaust system to be unblocked:

　　1)油板間或者運水集氣(煙)罩縫隙過小，這種情況較多;

　　1) the gap between the oil plate and the water collection gas (smoke) cover is too small, this situation is more;

　　2)煙罩內收集油煙的開口總的截面積太小而引起整體排煙不通暢;

　　2) the opening of the smoke collecting hood in the smoke hood is too small, so that the integral smoke exhaust is not unobstructed;

　　3)開口分布不合理或是開口沒有隨著與主管道的距離提升而提升，從而引起局部排煙不通暢。

　　3) the opening distribution is unreasonable or the opening does not increase with the distance between the main pipe and the main pipe, thus causing partial smoke exhaust is not smooth.

　　4、簡易不含擋油板和送風設備的集氣罩適合各種靈活機動場所，便于加工安裝，價格便宜。但由于沒有送風設備，集風效果相對較差，容易使油煙在廚房工作人員面前回旋，并且容易造成油滴散落。

　　4 、 simple air hood without oil baffle and air supply equipment is suitable for all kinds of flexible and flexible place, easy to process and install, and the price is cheap. But because there is no air supply equipment, the effect of collecting air is relatively poor, it is easy to make the oil smoke whirl in front of the kitchen staff, and easy to cause oil droplets scattered.

　　5、含擋油板和送風設備的集氣罩能夠較好地收集烹飪過程產生的油煙，油滴不散落，只要送風風量合理，廚房操作人員工作面的空氣質量就好。但安裝要求較高，投資較大。

　　5. The gas collecting hood with oil baffle and air supply device can better collect the smoke produced by cooking process, and the oil drops are not scattered. As long as the air supply volume is reasonable, the air quality of the working face of the kitchen operator is good. But the installation requirements are higher and the investment is larger.

　　本文由濟南排煙罩友情奉獻.更多有關的知識請點擊:http://www.zypolishing.com/我們將用先進的技術.真誠的態度.為您提供為多維度的服務.更多有關的知識我們將會陸續向大家奉獻.敬請期待.

　　In this paper, by the Ji'nan hood friendship devotion. More related knowledge: Please click http://www.zypolishing.com/ we will use the most advanced technology. The most sincere attitude, to provide you with the most comprehensive service. More related knowledge and we will continue to offer. Please look forward to.
